Features
High-Strength Frame
The newly engineered frame design effectively lowers stress by 51%, preventing fatigue fractures and offering greater strength than competing products.
Hydro-Pneumatic Suspension
Replacing leaf springs with hydro-pneumatic technology greatly improves machine comfort and durability, solves frequent front suspension breakage issues, and enhances machine uptime. It delivers superior shock absorption and damping to extend frame life.
Oil and Gas Suspension
Enhanced front oil and gas suspension provides better buffering and vibration reduction, reducing impacts on the frame, cab, and heavy parts, lowering fault frequency, and prolonging vehicle life by solving front leaf spring fractures.

Parameters
Net Weight: 29.5T
Engine Model: Weichai WP12G460E310
Gearbox Type: Fast 7DS200
Capacity (Struck/Heaped): 40m³
Size: 11300*3500*3950mm
Left/Right Hand Drive: Left/Right
Total Power: 338kW
Displacement: 11.7L
Maximum Torque: 2000NM
Max. Gradeability: 30%
Min. Turning Radius: 11000mm
Lubrication System: Optional automatic lubrication
Automatic/Manual: Automatic
Axle: 20+35+35T
Tyre: 14.00R25
Load Weight: 40T


Price: AED 3329000
Request for quote: +971525384269
