Features
With its low-stress and high-strength design, the new frame effectively prevents fatigue-related cracks and cuts overall stress levels by 51% relative to competitors.
The improved front oil and gas suspension system features enhanced buffering and vibration control, greatly reducing impacts on the frame, cab, and heavy components. This minimizes breakdowns and extends the lifespan of the vehicle, while completely addressing the issue of front leaf spring fractures.

Parameters
Automatic/Manual: Automatic/Manual
Axle: Pengxiang/Hande
Capacity (Struck/Heaped): 35/42(A)；38/44(M)m³
Displacement: 13L
Engine Model: Weichai WP13G530E310
Gearbox Type: Allison 4800RS_PR (A)/Fast 8DS260 (M)
Left/Right Hand Drive: Left/Right
Load Weight: 65/70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 30%
Maximum Torque: 2300NM
Min. Turning Radius: ＜12000mm
Net Weight: -T
Number/Type of Cylinders: 6,Straight type
Size: 9200*4000*4100mm
Total Power: 390kW
Tyre: 16R25.00 E3

Price: 1650000

For more details: +971525384269
