Features
High-Strength Frame
The advanced low-stress, high-strength frame prevents fatigue-related fractures and decreases overall stress by 51% compared to competitor products.
Hydro-Pneumatic Suspension
By replacing traditional leaf springs, the hydro-pneumatic suspension substantially improves machine comfort and longevity, resolves common front spring breakage problems, and increases operational uptime with superior shock absorption and damping.
Oil and Gas Suspension
The front oil and gas suspension system provides better buffering and vibration damping, greatly reducing impact forces on the frame, cab, and heavy components, minimizing faults, and extending vehicle service life by resolving front leaf spring fracture issues.

Parameters
Net Weight: 29.5T
Engine Model: Weichai WP12G460E310
Gearbox Type: Fast 7DS200
Capacity (Struck/Heaped): 40m³
Size: 11300*3500*3950mm
Left/Right Hand Drive: Left/Right
Total Power: 338kW
Displacement: 11.7L
Maximum Torque: 2000NM
Max. Gradeability: 30%
Min. Turning Radius: 11000mm
Lubrication System: Optional automatic lubrication
Automatic/Manual: Automatic
Axle: 20+35+35T
Tyre: 14.00R25
Load Weight: 40T


Price: AED 3329000
Request for quote: +971525384269
