Features
The advanced low-stress, high-strength frame design prevents fatigue fractures and lowers overall stress by 51% compared to competing products.
The front hydro-pneumatic oil and gas suspension system significantly improves shock absorption and vibration damping, drastically reducing the impact on the frame, cab, and other heavy parts. This reduces faults and extends the vehicle's life, completely solving the front plate spring fracture problem.

Parameters
Automatic/Manual: Automatic/Manual
Axle: Pengxiang/Hande
Capacity (Struck/Heaped): 35/42(A)；38/44(M)m³
Displacement: 13L
Engine Model: Weichai WP13G530E310
Gearbox Type: Allison 4800RS_PR (A)/Fast 8DS260 (M)
Left/Right Hand Drive: Left/Right
Load Weight: 65/70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 30%
Maximum Torque: 2300NM
Min. Turning Radius: ＜12000mm
Net Weight: -T
Number/Type of Cylinders: 6,Straight type
Size: 9200*4000*4100mm
Total Power: 390kW
Tyre: 16R25.00 E3

Price: 1650000

For more details: +971525384269
