Features
The newly developed frame, designed for low stress and high strength, effectively prevents fatigue fractures and cuts overall stress by 51% compared to competing models.
The front hydro-pneumatic oil and gas suspension system has been greatly enhanced to improve buffering and vibration control, significantly lowering impact forces on the frame, cab, and other heavy components. This reduces faults and extends the vehicle’s lifespan, completely resolving front leaf spring fractures.

Parameters
Automatic/Manual: Automatic/Manual
Axle: Pengxiang/Hande
Capacity (Struck/Heaped): 35/42(A)；38/44(M)m³
Displacement: 13L
Engine Model: Weichai WP13G530E310
Gearbox Type: Allison 4800RS_PR (A)/Fast 8DS260 (M)
Left/Right Hand Drive: Left/Right
Load Weight: 65/70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 30%
Maximum Torque: 2300NM
Min. Turning Radius: ＜12000mm
Net Weight: -T
Number/Type of Cylinders: 6,Straight type
Size: 9200*4000*4100mm
Total Power: 390kW
Tyre: 16R25.00 E3

Price: 1650000

For more details: +971525384269
