Features
Featuring a low-stress, high-strength design, the new frame successfully prevents fatigue-related breakage and reduces overall stress by 51% relative to competitors.
Improvements in the front oil and gas suspension system greatly enhance vibration damping and shock absorption, significantly reducing the impact on the frame, cab, and heavy parts. This decreases the chance of faults and prolongs vehicle durability, fully addressing the issue of front leaf spring fractures.

Parameters
Automatic/Manual: Automatic/Manual
Axle: Pengxiang/Hande
Capacity (Struck/Heaped): 35/42(A)；38/44(M)m³
Displacement: 13L
Engine Model: Weichai WP13G530E310
Gearbox Type: Allison 4800RS_PR (A)/Fast 8DS260 (M)
Left/Right Hand Drive: Left/Right
Load Weight: 65/70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 30%
Maximum Torque: 2300NM
Min. Turning Radius: ＜12000mm
Net Weight: -T
Number/Type of Cylinders: 6,Straight type
Size: 9200*4000*4100mm
Total Power: 390kW
Tyre: 16R25.00 E3

Price: 1650000
