Features
Precision in Motion
Delivers efficient, vertically accurate deep boreholes with high-speed lifting and smooth operation.
Strong Chassis Structure
Telescopic widening design and robust slewing bearing ensure excellent drilling stability.
Energy-Saving Performance
Imported EFI engine with intelligent control tech reduces fuel usage while enhancing responsiveness.

Parameters
Main Chassis
Base Engine: Isuzu 6HK1
Engine Power: 212/2000kW/rpm
Emission Regulation: China Stage III
Rotary Drive
Rated Speed: 5~30rpm
Rated Output Torque: 220kN·m
Pile
Max. Pile Diameter: 1800mm
Max. Pile Depth: 64/51m
Crowd System
Crowd Force: 180kN
Stroke: 4200mm
Line Pull: 190kN
Overall Machine
Overall Height: 21040mm
Operating Weight: 63T
Transport Width: 3510mm
Transport Height: 3560mm
Main Winch
Lifting Capacity: 220kN
Max. Line Speed: 75m/min
Rope Diameter: 28mm


Price: AED 2500000
Request for quote: +971525384269
