The newly designed frame, combining low stress and high strength, effectively stops fatigue-induced fractures and lowers the overall stress by 51% compared to rival products.
Front oil and gas suspension with hydro-pneumatic technology has been significantly upgraded to improve vibration reduction and buffering. This greatly lessens the impact on the frame, cab, and heavy parts, reducing malfunctions and prolonging vehicle life, while fully resolving front leaf spring breakage issues.

Parameters
Automatic/Manual: Automatic/Manual
Axle: Pengxiang/Hande
Capacity (Struck/Heaped): 35/42(A)；38/44(M)m³
Displacement: 13L
Engine Model: Weichai WP13G530E310
Gearbox Type: Allison 4800RS_PR (A)/Fast 8DS260 (M)
Left/Right Hand Drive: Left/Right
Load Weight: 65/70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 30%
Maximum Torque: 2300NM
Min. Turning Radius: ＜12000mm
Net Weight: -T
Number/Type of Cylinders: 6,Straight type
Size: 9200*4000*4100mm
Total Power: 390kW
Tyre: 16R25.00 E3

Price: 1650000
