Features
This innovative frame design combines high strength with low stress, reducing fatigue breakage and lowering overall stress by 51% compared to other products. The hydro-pneumatic suspension system replaces the old leaf spring setup, greatly improving machine comfort and lifespan, eradicating frequent front suspension spring breaks, and enhancing machine availability. Meanwhile, the front oil and gas suspension dramatically enhances buffering and vibration damping, significantly lessening the impact on the frame, cab, and heavy components, reducing failures, prolonging vehicle life, and solving front plate spring fracture issues.

Parameters
Automatic/Manual: Automatic
Capacity (Struck/Heaped): 38/44m³
Displacement: -L
Engine Model: DET6S360
Gearbox Type: Double 3-gear AMT
Load Weight: 70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 35%
Maximum Torque: 21000NM
Min. Turning Radius: 13500mm
Net Weight: 38T
Size: 10050*3980*4680mm
Total Power: 820kW
Tyre: 16.00R25 E3



Price: AED 2255000
Request for quote: +971525384269
