Features
The frame features a new low-stress, high-strength design that effectively prevents fatigue breakage and cuts overall stress by 51% versus competitors. Hydro-pneumatic suspension technology replaces traditional leaf springs, markedly improving machine comfort and lifespan while solving frequent front suspension spring failures to boost uptime. Front oil and gas suspension enhancements provide superior buffering and vibration reduction, significantly lowering impact on the frame, cab, and heavy parts, decreasing faults, extending vehicle life, and thoroughly resolving front plate spring fractures.

Parameters
Automatic/Manual: Automatic
Capacity (Struck/Heaped): 38/44m³
Displacement: -L
Engine Model: DET6S360
Gearbox Type: Double 3-gear AMT
Load Weight: 70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 35%
Maximum Torque: 21000NM
Min. Turning Radius: 13500mm
Net Weight: 38T
Size: 10050*3980*4680mm
Total Power: 820kW
Tyre: 16.00R25 E3



Price: AED 2255000
Request for quote: +971525384269
