Features
This newly designed frame boasts high strength and low stress, preventing fatigue failure and reducing total stress by 51% compared to rival products. The hydro-pneumatic suspension system replaces conventional leaf springs, boosting machine longevity and ride comfort, fixing frequent front suspension spring breaks, and improving operational reliability. The front oil and gas suspension system significantly improves shock absorption and vibration control, minimizing impact forces on the frame, cab, and heavy parts, decreasing faults, extending vehicle lifespan, and fully addressing front plate spring breakage.

Parameters
Automatic/Manual: Automatic
Capacity (Struck/Heaped): 38/44m³
Displacement: -L
Engine Model: DET6S360
Gearbox Type: Double 3-gear AMT
Load Weight: 70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 35%
Maximum Torque: 21000NM
Min. Turning Radius: 13500mm
Net Weight: 38T
Size: 10050*3980*4680mm
Total Power: 820kW
Tyre: 16.00R25 E3



Price: AED 2255000
Request for quote: +971525384269
