Features
High-Speed, High-Accuracy
Ideal for deep civil drilling projects, delivering quick lifting speeds and consistent vertical alignment for precise results.
Robust Chassis Platform
Telescopic wide chassis with a large slewing bearing ensures unmatched stability under deep drilling conditions.
Energy-Conscious Power System
Features a fuel-efficient EFI engine with advanced power management for lower consumption and faster reaction times.

Parameters
Main Chassis
Base Engine: Isuzu 6HK1
Engine Power: 212/2000kW/rpm
Emission Regulation: China Stage III
Rotary Drive
Rated Speed: 5~30rpm
Rated Output Torque: 220kN·m
Pile
Max. Pile Diameter: 1800mm
Max. Pile Depth: 64/51m
Crowd System
Crowd Force: 180kN
Stroke: 4200mm
Line Pull: 190kN
Overall Machine
Overall Height: 21040mm
Operating Weight: 63T
Transport Width: 3510mm
Transport Height: 3560mm
Main Winch
Lifting Capacity: 220kN
Max. Line Speed: 75m/min
Rope Diameter: 28mm


Price: AED 2500000
Request for quote: +971525384269
