Features
Enhanced Drilling Efficiency
With high torque and crowd force combined with a fast main rope line speed, this machine delivers excellent drilling performance in hard soil layers. Ideal for large hole foundations in overpasses, high-speed rail, and major buildings.
Winch Crowd System with Full Stroke
Equipped with a long-stroke winch crowd system and fast crowding capability, along with a rotary drive display, making it perfect for casing work in challenging formations like beaches, pebble layers, and backfill soils.
Economical and Efficient Power Use
Adopts power optimization technology for real-time, smooth power distribution, providing fast response and high fuel efficiency with reduced overall fuel consumption.

Parameters
Main Chassis
Base Engine: Cummins X15
Engine Power: 391/1800kW/rpm
Emission Regulation: Stage V/Tier4 final
Rotary Drive
Rated Speed: 7~26rpm
Rated Output Torque: 400kN·m
Pile
Max. Pile Diameter: 2500mm
Max. Pile Depth: 103/86m
Crowd System
Crowd Force: 405kN
Stroke: 9000/19000mm
Line Pull: 405kN
Overall Machine
Overall Height: 27430mm
Operating Weight: 137T
Transport Width: 3600mm
Transport Height: 3380mm
Main Winch
Lifting Capacity: 410kN
Max. Line Speed: 66m/min
Rope Diameter: 36mm


Price: AED 2830000
Request for quote: +971525384269
