Features
The innovative low-stress, high-strength frame design prevents fatigue breakage and decreases total stress by 51% when compared with other products.
The hydro-pneumatic oil and gas suspension system at the front offers superior buffering and vibration reduction, greatly diminishing the impact on the frame, cab, and heavy components. This improvement lowers failure rates and extends the machine's service life while eliminating front leaf spring fractures.

Parameters
Automatic/Manual: Automatic/Manual
Axle: Pengxiang/Hande
Capacity (Struck/Heaped): 35/42(A)；38/44(M)m³
Displacement: 13L
Engine Model: Weichai WP13G530E310
Gearbox Type: Allison 4800RS_PR (A)/Fast 8DS260 (M)
Left/Right Hand Drive: Left/Right
Load Weight: 65/70T
Lubrication System: Optional automatic lubrication
Max. Gradeability: 30%
Maximum Torque: 2300NM
Min. Turning Radius: ＜12000mm
Net Weight: -T
Number/Type of Cylinders: 6,Straight type
Size: 9200*4000*4100mm
Total Power: 390kW
Tyre: 16R25.00 E3

Price: 1650000
