Features
Fuel-Efficient Engine with Strong Torque
Jointly developed with global suppliers, the engine offers long-term stability, complies with Tier IV/III emissions, and minimizes operating costs with low fuel consumption.
Deep Stroke Design for Complex Terrain
Its 15-meter full-stroke capability is ideal for deep drilling, providing quick push/pull actions in tough formations like sand, fill, or gravel.
Smart Kelly Lock Display System
Displays the lock position on-screen to assist operators with safe and accurate handling of the Kelly bar.

Parameters
Standard Mode
Crowd Force: 180kN
Stroke: 14300mm
Overall Height: 21040mm
Max. Pile Diameter: 1600mm
Max. Pile Depth: 59/47m
Operating Weight: 63T
Line Pull: 180kN
Rated Speed: 5~34rpm
Rated Output Torque: 190kN·m
Main Chassis
Base Engine: ISUZU 6HK1
Engine Power: 212/2000kW/rpm
Emission Regulation: China Stage III
Overall Machine
Transport Width: 3215mm
Transport Height: 3495mm
Main Winch
Lifting Capacity: 185kN
Max. Line Speed: 75m/min
Rope Diameter: 28mm


Price: AED 1925000
Request for quote: +971525384269
