Features
High Precision & Productivity
Handles deep drilling tasks with speed and accuracy, ideal for demanding construction sites.
Enhanced Chassis System
Telescopic wide chassis and large slewing bearing provide excellent support and drilling consistency.
Advanced Fuel Control
EFI engine dynamically adjusts power distribution to minimize energy waste and maximize performance.

Parameters
Main Chassis
Base Engine: Isuzu 6HK1
Engine Power: 212/2000kW/rpm
Emission Regulation: China Stage III
Rotary Drive
Rated Speed: 5~30rpm
Rated Output Torque: 220kN·m
Pile
Max. Pile Diameter: 1800mm
Max. Pile Depth: 64/51m
Crowd System
Crowd Force: 180kN
Stroke: 4200mm
Line Pull: 190kN
Overall Machine
Overall Height: 21040mm
Operating Weight: 63T
Transport Width: 3510mm
Transport Height: 3560mm
Main Winch
Lifting Capacity: 220kN
Max. Line Speed: 75m/min
Rope Diameter: 28mm


Price: AED 2500000
Request for quote: +971525384269
