Features
Energy-Conserving Power Control
Dynamic power distribution technology provides fast, smooth composite operations with enhanced fuel efficiency.
Step Drum Durability
Single-layer step drum prevents wire rope damage, extending service life by 35%.
Responsive HD Touchscreen
An HD touchscreen with a 3ms refresh rate delivers fluid animation and sharp display.

Parameters
Main Chassis
Base Engine: Isuzu 6WG1
Engine Power: 377/1800kW/rpm
Emission Regulation: China Stage Ⅲ
Rotary Drive
Rated Speed: 5~25rpm
Rated Output Torque: 405kN·m
Pile
Max. Pile Diameter: 2500/2200mm
Max. Pile Depth: 103/84m
Crowd System
Crowd Force: 350kN
Stroke: 13000mm
Line Pull: 400kN
Overall Machine
Overall Height: 27700mm
Operating Weight: 131T
Transport Width: 3500mm
Transport Height: 3660mm
Main Winch
Lifting Capacity: 400kN
Max. Line Speed: 75m/min
Rope Diameter: 36mm


Price: AED 3325000
Request for quote: +971525384269
