Features
High-Strength Frame
With a low-stress and high-strength design, the new frame reduces overall stress by 51%, effectively preventing fatigue breakage compared to competitors.
Hydro-Pneumatic Suspension
This hydro-pneumatic suspension replaces the traditional leaf spring system, enhancing machine durability and comfort, resolving frequent front suspension spring breakage, and increasing uptime. It features excellent shock absorption and damping for improved load management and longer frame life.
Oil and Gas Suspension
Front oil and gas suspension improvements significantly enhance buffering and vibration reduction, reducing the impact on the frame, cab, and other heavy parts, minimizing faults, and extending vehicle lifespan by addressing front leaf spring fractures.

Parameters
Net Weight: 29.5T
Engine Model: Weichai WP12G460E310
Gearbox Type: Fast 7DS200
Capacity (Struck/Heaped): 40m³
Size: 11300*3500*3950mm
Left/Right Hand Drive: Left/Right
Total Power: 338kW
Displacement: 11.7L
Maximum Torque: 2000NM
Max. Gradeability: 30%
Min. Turning Radius: 11000mm
Lubrication System: Optional automatic lubrication
Automatic/Manual: Automatic
Axle: 20+35+35T
Tyre: 14.00R25
Load Weight: 40T


Price: AED 3329000
Request for quote: +971525384269
