Features
Energy Saving & Performance
Power optimization control technology allows for real-time power allocation with rapid compound response, reducing fuel consumption by up to 15%.
Interactive Touchscreen
High-definition touchscreen with 3ms refresh frequency ensures smooth visuals. SANY’s patented locking visualization technology reduces wear and prevents Kelly bar accidents.
Convenient Maintenance
Rotary drive external driving key simplifies servicing. Wedge-fixed main winch wire rope end ensures quick assembly/disassembly. Lubrication is easy through a special point connected to an outlet hose.

Parameters
Main Chassis
Base Engine: Isuzu 6WG1
Engine Power: 300/1800kW/rpm
Emission Regulation: China Stage Ⅲ
Rotary Drive
Rated Speed: 5~25rpm
Rated Output Torque: 360kN·m
Pile
Max. Pile Diameter: 2500mm
Max. Pile Depth: 100/65m
Crowd System
Crowd Force: 290kN
Stroke: 6000mm
Line Pull: 335kN
Overall Machine
Overall Height: 26365mm
Operating Weight: 120T
Transport Width: 3530mm
Transport Height: 3745mm
Main Winch
Lifting Capacity: 360kN
Max. Line Speed: 75m/min
Rope Diameter: 36mm


Price: AED 3329000
Request for quote: +971525384269
