Features
Fuel Saving Technology
Real-time power control ensures efficient energy distribution and fast compound response, lowering fuel consumption by 10–15%.
Advanced Touchscreen
Features a 3ms refresh high-definition touchscreen with smooth animations. Patented locking visualization technology by SANY reduces wear and the risk of Kelly bar accidents.
Maintenance Efficiency
External rotary drive key allows easy access for repairs. The wedge-fixed main winch wire rope can be quickly removed and installed. Grease injection is facilitated via a special lubrication point connected to an outlet hose.


Parameters
Main Chassis
Base Engine: Isuzu 6WG1
Engine Power: 300/1800kW/rpm
Emission Regulation: China Stage Ⅲ
Rotary Drive
Rated Speed: 5~25rpm
Rated Output Torque: 360kN·m
Pile
Max. Pile Diameter: 2500mm
Max. Pile Depth: 100/65m
Crowd System
Crowd Force: 290kN
Stroke: 6000mm
Line Pull: 335kN
Overall Machine
Overall Height: 26365mm
Operating Weight: 120T
Transport Width: 3530mm
Transport Height: 3745mm
Main Winch
Lifting Capacity: 360kN
Max. Line Speed: 75m/min
Rope Diameter: 36mm


Price: AED 3329000
Request for quote: +971525384269
